Application teardowns
These pages take a real product apart. A laser diode on its own is a data sheet; inside a rangefinder it is a decision about range, eye safety and size. Pick a part from a bill of materials and read the parameters that decide how the whole thing performs - each one with the catalogue part numbers that carry it.
905 nm application teardown
Emitter, detector, optics and driver board: the four parts behind any 905 nm ranging design.
905 nm laser diodeAvalanche photodiodeOpticsDrive and timing electronics
Parts: 4 · Catalogue parts: 11
Rangefinding scope teardown
Day optics, a 905 nm transmit chain, a detector and the timing electronics - plus what changes for an eye-safe 1535 nm build.
905 nm laser diodeAvalanche photodiodeDay and ranging opticsControl and timing electronics
Parts: 4 · Catalogue parts: 20
Golf rangefinder teardown
A compact 905 nm transmit chain, a small-area detector, the timing electronics and the tilt / display module - the short-range end of the ranging family, with the user interface on top.
905 nm laser diodeAvalanche photodiodeEmit / receive opticsDrive and timingTilt and display
Parts: 5 · Catalogue parts: 14
LiDAR teardown
A 905 nm transmit chain and an APD receive chain carried on a rotor: the same ranging parts the other modules use, plus the scan mechanism, the detector bias supply and the optical bench that turn a distance into a scan.
905 nm laser diodeAvalanche photodiodeExit window and transmit / receive opticsRotor, motor and encoderTiming and signal-processing boardPower and detector biasShell, optical bench and interface
Parts: 7 · Catalogue parts: 20
Send us the requirement - range, target, size, budget - and an engineer will come back with parts and the trade-offs between them.
